Spesification Network Transceiver DEM-432XT
Long-Range 10G Fiber Transceiver for Enterprise Networks
The D-Link DEM-432XT is a high-performance 10GBase-LR SFP+ transceiver designed to deliver ultra-fast and reliable fiber connectivity across long distances. Operating at a wavelength of 1310 nm, it supports transmission up to 10 kilometers over single-mode fiber, making it ideal for enterprise backbones, data centers, and campus networks requiring high-speed interconnects.
With its Enhanced Small Form-Factor Pluggable (SFP+) design, the DEM-432XT is hot-pluggable, allowing seamless installation and replacement without service interruption. It complies with IEEE 802.3ae standards, ensuring compatibility with industry-standard networking equipment. Digital Diagnostics Monitoring (DDM) provides real-time insights into transceiver health, including temperature, voltage, and optical power, enabling proactive maintenance and stable operations.
Built with a durable metal housing, the DEM-432XT reduces electromagnetic interference (EMI) and enhances reliability in demanding environments. RoHS compliance and adherence to the Multi-Source Agreement (MSA) guarantee environmental responsibility and interoperability across multiple vendor platforms. Compact yet powerful, the DEM-432XT is the trusted solution for organizations seeking scalable, long-range 10G fiber connectivity.
Category : Network
Brand : D-Link
Product : DEM-432XT
Description
Features – D-Link DEM-432XT
10GBase-LR Connectivity – Supports 10 Gigabit Ethernet over single-mode fiber.
Long-Distance Transmission – Up to 10 km at 1310 nm wavelength.
Enhanced SFP+ Form Factor – Compact, hot-pluggable design for easy deployment.
Digital Diagnostics Monitoring (DDM) – Real-time monitoring of temperature, voltage, and optical power.
Standards Compliance – IEEE 802.3ae compliant for wide compatibility.
MSA Compliant – Ensures interoperability with multiple vendor equipment.
RoHS Compliant – Environmentally responsible design.
Durable Metal Housing – Reduces EMI and increases reliability.
Enterprise-Grade Reliability – Built for backbone links, data centers, and high-performance networks.
Features
D-Link DEM-432XT – 10GBASE-SR SFP+ Transceiver
Overview
| Product Type | SFP+ Transceiver Module |
|---|---|
| Application | 10 Gigabit Ethernet over multi-mode fiber |
| Status | Active Product |
| Warranty | 2-Year Limited Warranty |
General Specifications
| Standard | IEEE 802.3ae 10GBASE-SR |
|---|---|
| Connector | Duplex LC |
| Operation | Full Duplex |
| Hot Pluggable | Yes |
Optical Characteristics
| Fiber Type | Multi-mode fiber (OM3/OM4) |
|---|---|
| Maximum Distance | Up to 300 m (OM3), up to 400 m (OM4) |
| Wavelength | 850 nm |
| Transmit Power | -7.3 to -1 dBm |
| Receiver Sensitivity | -11.1 dBm (max) |
| Power Budget | 3.8 dB |
Electrical & Physical
| Support Voltage | 3.3 V |
|---|---|
| Max Current | 300 mA |
| Laser Class | Class 1 (EN60825-1 compliant) |
| Enclosure | Metal housing (reduces EMI, increases durability) |
| Dimensions | 13.8 x 56.5 x 8.5 mm |
| Weight | ~18 g |
Features
| Feature 1 | High-performance 850 nm multi-mode SFP+ transceiver |
|---|---|
| Feature 2 | Supports 10 Gigabit speeds with full duplex operation |
| Feature 3 | Compatible with D-Link 10G switches and routers |
| Feature 4 | Hot pluggable for easy installation |
| Feature 5 | Metal enclosure for lower EMI and durability |
Compliance
| Industry Standards | IEEE 802.3ae, EN60825-1, FDA 21 1040.10 & 1040.11 |
|---|---|
| Safety | Class 1 Laser Product |
Order Information
| Model | DEM-432XT – 10GBASE-SR SFP+ Transceiver |
|---|---|
| Related Models | DEM-431XT (10GBASE-LR, single-mode, up to 10 km) |
