APC Easy UPS SMV 750VA, Universal Outlet, 230V (SMV750I-MS)

APC Easy UPS SMV 750VA, Universal Outlet, 230V (SMV750I-MS) Compact line-interactive UPS with 525W pure sine wave output and automatic voltage regulation. Designed for small offices, workstations, and POS systems. Features LCD control panel, universal outlets, and reliable battery backup for essential electronics.

Description

⚙️ Key Specifications
• Model: SMV750I-MS
• UPS Type: Line-Interactive
• Power Capacity: 750VA / 525W
• Nominal Input Voltage: 230V (range: 165–290V ±5V)
• Nominal Output Voltage: 230V
• Input Frequency: 50/60 Hz ±1 Hz (auto-sensing)
• Output Frequency: 50/60 Hz ±1 Hz (unsynchronized)
• Waveform Type: Pure sine wave
• Voltage Regulation: Automatic Voltage Regulation (AVR)
• Transfer Time: 2–6 ms typical, 12 ms max
• Crest Factor: 3:1
🔋 Battery System
• Battery Type: Sealed lead-acid (VRLA), maintenance-free
• Battery Configuration: 2 × 12V / 7Ah
• Battery Voltage: 24V DC
• Recharge Time: 4–6 hours to 90% capacity
• Battery Life Expectancy: 3–5 years
• Replacement Battery: APCRBCV206
• Extended Runtime: Not supported
🧩 Features & Connectivity
• Display: LCD panel with real-time status indicators
• Control Panel Modes:
• AC Mode
• AVR Mode
• Battery Mode
• Battery Level
• Load Level
• Input/Output Voltage
• System Error
• Battery Malfunction
• Audible Alarms:
• Battery mode
• Low battery
• Overload
• Interface Ports: USB, RS-232
• Surge Protection: 190 Joules
• Output Connections: 4 × Universal battery backup outlets
• Input Connection: IEC C14
📦 Dimensions & Weight
• Unit Dimensions (HxWxD): 220 × 160 × 410 mm
• Shipping Dimensions: 339 × 272 × 508 mm
• Net Weight: 13.6 kg
• Shipping Weight: 16.6 kg
• Mounting Mode: Tower only (non-rackable)
• Color: Black
✅ Certifications & Environment
• Certifications: CE, TISI
• Protection Class: IP20
• Operating Temperature: 0–40°C
• Humidity Range: 0–95% (non-condensing)
• Altitude: Up to 3000 m
• Noise Level: ≤ 45 dBA
• Warranty: 2 years repair or replace
