APC Easy UPS SRV 72V Battery Pack for 2&3kVA Tower, No Battery Model (SRV72BP-9A)
APC Easy UPS SRV 72V Battery Pack for 2&3kVA Tower, No Battery Model (SRV72BP-9A) External tower-style battery enclosure designed to extend runtime for APC Easy UPS SRV 2kVA and 3kVA models. Supports 72V DC configuration with scalable backup capability. Ships without batteries, allowing flexible customization for business continuity needs.
Description
⚙️ Key Specifications
- Model: SRV72BP-9A
- Product Type: External Battery Pack
- Compatible UPS Models: APC Easy UPS SRV2KIL-E, SRV3KIL-E (2kVA & 3kVA Tower Extended Runtime)
- Battery Voltage: 72V DC
- Battery Type: Sealed Maintenance-Free (SMF) Lead-Acid, 12V 9Ah
- Battery Quantity: 12 batteries (not included in No Battery Model)
- Battery Capacity: 1296VAh (when fully populated)
- Battery Expansion: Supports up to 4 battery packs in parallel
- Runtime Extension: Yes, scalable with multiple packs
🧩 Features & Equipment
- Form Factor: Tower
- Application: Network and server environments
- Included Accessories:
- Battery cable
- User manual
- CD media
- Color: Black
📦 Dimensions & Weight
- Unit Dimensions (HxWxD): Approx. 24 × 60 × 50 cm
- Net Weight: Varies depending on battery inclusion
- Shipping Weight: ±24.2 kg (without batteries)
✅ Certifications & Environment
- Certifications: CE, UKCA, EAC, EN/IEC 62040-1
- Operating Temperature: 0–40°C
- Humidity Range: 0–95% (non-condensing)
- Altitude (Operation): Up to 3000 m
- Altitude (Storage): Up to 15000 m
- Warranty: 1 year (APC official warranty
