APC Smart-UPS RT 192V 9Ah Battery Pack 2 Rows (SRTG192XLBP2)

APC Smart-UPS RT 192V Battery Pack 2 Rows (SRTG192XLBP2) High-capacity external battery pack with 192V DC output and 9Ah sealed lead-acid cells, designed for APC Smart-UPS RT 15–20kVA models. Rackmountable 4U form factor with dual-row configuration, scalable runtime support, and ideal for mission-critical IT environments.

Description

⚙️ Key Specifications
• Model: SRTG192XLBP2
• Product Type: External Battery Pack
• Compatible UPS Models: APC Smart-UPS RT 15kVA / 20kVA
• Battery Voltage: 192V DC
• Battery Type: Sealed Lead-Acid (VRLA), maintenance-free
• Battery Capacity: 9Ah per cell
• Battery Configuration: 2 rows of batteries
• Battery Replacement Cartridge: APCRBC172
• Battery Slots (Filled/Free): 4 / 0
• Battery Expansion: Supports up to 4 packs in parallel
• Runtime Extension: Yes, scalable with multiple packs
🧩 Features & Equipment
• Form Factor: Rackmount (4U height)
• Mounting Mode: Rack-mounted or standalone stack
• Rail Kit: Optional (SRTGRK2 sold separately)
• Included Accessories:
• Installation guide
• Warranty card
• USB Compatible: No
• Color: Black
📦 Dimensions & Weight
• Unit Dimensions (HxWxD): 175 × 440 × 700 mm
• Net Weight: ±116 kg
• Shipping Dimensions: 295 × 790 × 590 mm
• Shipping Weight: ±122.4 kg
✅ Certifications & Environment
• Certifications: CE, EN/IEC 62040-1
• Operating Temperature: 0–40°C
• Humidity Range (Operation & Storage): 0–95% (non-condensing)
• Altitude (Operation): Up to 2000 m
• Altitude (Storage): Up to 15240 m
• Warranty: 2 years repair or replace
