ThinkPad X Series

Description

Performance

• Processor Options:
  • Latest Intel® Core™ Ultra processors (U/P series) with optional Intel® vPro® support
  • Some models also offer AMD Ryzen™ PRO processors
• Graphics: Integrated Intel® Iris Xe / Intel® Arc graphics; optional NVIDIA® GeForce RTX™ discrete GPU on select models (e.g., X1 Extreme)
• Operating System: Windows 11 Pro (default), Linux options available

Memory & Storage

• RAM: DDR5 (or LPDDR5 soldered in ultrathin models), up to 64GB depending on model
• Storage: PCIe NVMe SSD, up to 2TB; some models support dual drives (X1 Extreme)
• Upgradeable: Limited on ultrathin models (X1 Carbon, X1 Yoga), more flexible on X1 Extreme

Display

• Sizes:
  • X1 Carbon: 14″
  • X1 Yoga: 14″ (convertible 2-in-1)
  • X1 Extreme: 16″
• Resolution Options:
  • FHD (1920×1080) IPS, anti-glare
  • 2.8K OLED or UHD+ (3840×2400) IPS/OLED with HDR400, Dolby Vision®
• Brightness: 400–600 nits depending on panel
• Touchscreen: Available on Yoga and OLED variants
• Aspect Ratio: 16:10 for modern models

Audio & Camera

• Speakers: Dolby Atmos® stereo speakers
• Camera: FHD 1080p or IR hybrid with Privacy Shutter; optional 5MP camera on X1 Yoga/Extreme
• Microphone: Quad-array microphones with noise cancellation

Battery & Power

• Battery Options: 57Wh to 86Wh depending on model
• Rapid Charge: Up to 80% in 1 hour
• Battery Life: Typically 10–15 hours depending on configuration

Design & Dimensions

• Material: Carbon fiber, magnesium alloy, or aluminum depending on model
• Weight:
  • X1 Carbon: ~1.1–1.2 kg
  • X1 Yoga: ~1.3–1.4 kg
  • X1 Extreme: ~1.8–2.0 kg
• Durability: MIL-STD 810H military certification
• Keyboard: Spill-resistant ThinkPad keyboard with TrackPoint and multi-touch trackpad

Connectivity & Ports

• Wi-Fi: Wi-Fi 6E
• Bluetooth: Version 5.3
• Ports:
  • USB-C / Thunderbolt™ 4
  • USB-A 3.2
  • HDMI 2.0/2.1
  • Audio combo jack
  • Optional SD card reader (X1 Extreme)
• Docking: Compatible with ThinkPad Thunderbolt and USB-C docks

Summary

• The ThinkPad X Series is Lenovo’s ultra-premium business laptop line, offering lightweight design, powerful performance, and enterprise-grade features.
• Key strengths: carbon fiber durability, high-resolution OLED/UHD+ displays, long battery life, and advanced security.
• Popular models:
  • X1 Carbon – ultralight flagship business laptop
  • X1 Yoga – convertible 2-in-1 with pen support
  • X1 Extreme – high-performance workstation-class laptop for creators and power users
